  • 12kV High Voltage Load Disconnect Switch DCD-12

    XUDIAN is a 14 yeas' manufacturer engaged in Disconnect Switch,Surge Arrester,Polymer Insulator,Cut-off Fuse,HV Vacuum circuit breaker ect High Voltage Equipments ects.

    DCD-12 ,suitable for power system with rated voltage 10KV , to connect or disconnect power when voltage load.

    Advantage: High performance,connect reliable,big flow capacity,with arcing capacity.

    Polymer type  with anti-polution and no need clean.

    Using Condition

    1.Plane type altitude less than 2000m, Highland type altitude less than 4000.
    2.Temperature:-30°C~40°C;
    3.Wind pressure:700Pa (34m/s)
    4.Earthquake level less than 8 Level.
    5.Area without  frequently strenuous vibration.
    6.Be installed in a place no effect the disconnect switch, no, corrosive gas, and strenuous vibration.
